Chunking Strategies and Embeddings for Better RAG

When a retrieval system returns the wrong passage, the fix people reach for is a better prompt or a bigger model. Neither helps. If the right text was never retrieved, nothing downstream can recover it, and retrieval quality is decided almost entirely by two things: how you split the documents, and how you search the resulting vectors.

This is the layer underneath a RAG pipeline, and it is where the largest quality gains are available.

What is an embedding, actually?

An embedding model reads a piece of text and returns a fixed-length list of numbers, typically several hundred to a few thousand of them. Text with similar meaning produces vectors that point in similar directions, which is what makes it possible to search by meaning instead of by keyword.

Similarity is almost always cosine similarity: the angle between two vectors, ignoring their length. Two texts about the same subject score near 1, unrelated texts near 0.

Which model to embed with is a question with a public answer rather than a matter of taste. The MTEB leaderboard ranks embedding models across retrieval, clustering and reranking tasks, and it is the right place to start rather than the first model in whichever tutorial you read. Filter it by the retrieval column, then by dimension count, because a 3,072-dimension vector costs real storage and query time over millions of chunks.

function cosineSimilarity(a: number[], b: number[]): number {
  let dot = 0;
  let normA = 0;
  let normB = 0;

  for (let i = 0; i < a.length; i++) {
    dot += a[i] * b[i];
    normA += a[i] * a[i];
    normB += b[i] * b[i];
  }

  return dot / (Math.sqrt(normA) * Math.sqrt(normB));
}

You will rarely write that, because the database does it. It is worth seeing once, because it makes clear that the whole mechanism is a geometric comparison with no understanding of your domain in it.

Chunking strategies are the highest-leverage decision

A chunk is the unit of retrieval. Whatever you retrieve is what the model sees, so a chunk needs to be small enough to be specific and large enough to make sense on its own. Those pull in opposite directions, which is why this is a real decision rather than a default.

Why does fixed-size chunking underperform?

// The version in every quickstart.
function fixedChunks(text: string, size = 1000, overlap = 200): string[] {
  const out: string[] = [];
  for (let i = 0; i < text.length; i += size - overlap) {
    out.push(text.slice(i, i + size));
  }
  return out;
}

It is simple, predictable, and it cuts through the middle of sentences, splits tables from their headers, and separates "the following three conditions apply" from the three conditions. Every one of those produces a chunk that embeds poorly, because half a thought has an ambiguous meaning.

Structure-aware chunking

Documents already tell you where the boundaries are. Headings, sections, paragraphs. Splitting on those and only falling back to character counts when a section is genuinely too long produces chunks that are coherent by construction.

type Chunk = { text: string; heading: string };

function chunkMarkdown(markdown: string, maxChars = 1200): Chunk[] {
  const sections = markdown.split(/^(?=#{1,3} )/m);
  const chunks: Chunk[] = [];

  for (const section of sections) {
    const heading = section.match(/^#{1,3} (.+)$/m)?.[1] ?? '';

    if (section.length <= maxChars) {
      chunks.push({ text: section.trim(), heading });
      continue;
    }

    // Too long: split on paragraphs, packing them up to the limit.
    let buffer = '';
    for (const para of section.split(/\n\s*\n/)) {
      if (buffer.length + para.length > maxChars && buffer) {
        chunks.push({ text: buffer.trim(), heading });
        buffer = '';
      }
      buffer += para + '\n\n';
    }
    if (buffer.trim()) chunks.push({ text: buffer.trim(), heading });
  }

  return chunks;
}

Prepend the context the chunk lost

This one is small and it consistently outperforms more elaborate techniques. A chunk taken from the middle of a document has lost the information that it belongs to that document, under that heading. Put it back before embedding. Anthropic published a fuller version of the same idea as contextual retrieval, generating a sentence of situating context per chunk with a model rather than templating it from the heading. That costs a generation call per chunk at index time. The cheap templated version below gets a good share of the benefit for nothing, so start there and measure before paying for the elaborate one.

// Embed this, not the bare chunk text.
const embedText = [
  `Document: ${doc.title}`,
  chunk.heading ? `Section: ${chunk.heading}` : '',
  '',
  chunk.text,
]
  .filter(Boolean)
  .join('\n');

A chunk reading "It must be renewed every 12 months" is close to meaningless in isolation and matches almost any question about renewal. The same chunk prefixed with "Document: TLS Certificate Policy / Section: Expiry" is now specific, and it stops competing with the renewal section of nine other documents.

How big should chunks be?

There is no universal answer, but the shape of the tradeoff is consistent:

I start at roughly 1,000 characters with structure-aware splitting, then measure. Which brings up the part that makes all of this tractable.

Measure retrieval separately from generation

The mistake that keeps teams stuck is evaluating the final answer. When the answer is wrong you cannot tell whether retrieval missed or the model mishandled good context, so you tune both at once and learn nothing.

Test retrieval on its own. Write out questions with the chunk that should be returned, then measure how often it appears in the top k.

type Example = { question: string; expectedChunkId: string };

async function recallAtK(examples: Example[], k: number): Promise<number> {
  let hits = 0;
  for (const ex of examples) {
    const results = await search(ex.question, { limit: k });
    if (results.some((r) => r.id === ex.expectedChunkId)) hits++;
  }
  return hits / examples.length;
}

// Compare chunking strategies on the same questions.
console.log('recall@5 ', await recallAtK(examples, 5));
console.log('recall@20', await recallAtK(examples, 20));

The gap between those two numbers tells you what to do next. High recall@20 with low recall@5 means retrieval finds the right chunk but ranks it poorly, which is a reranking problem. Low recall@20 means it is not being found at all, which is a chunking or embedding problem. Those need completely different fixes, and without the two numbers you cannot tell which one you have.

Where does vector search alone fail?

Embeddings are good at meaning and bad at exact tokens. Ask about part number MX-4021-B and the search returns chunks about part numbers generally, because to an embedding model that string is semantically similar to every other product code.

The affected categories are predictable: identifiers and SKUs, error codes, version numbers, people's names, acronyms, and negation. Negation deserves a mention because it is invisible until it bites: "refunds are available" and "refunds are not available" embed to nearly the same vector.

Hybrid search

Run keyword search alongside vector search and combine the results. Postgres does both, so this does not require another system: pgvector documents the hybrid pattern against tsvector, which is the same shape as the query below.

const [semantic, keyword] = await Promise.all([
  db.query(
    `SELECT id FROM chunks ORDER BY embedding <=> $1 LIMIT 30`,
    [toVector(queryVector)]
  ),
  db.query(
    `SELECT id FROM chunks
     WHERE tsv @@ plainto_tsquery('english', $1)
     ORDER BY ts_rank(tsv, plainto_tsquery('english', $1)) DESC
     LIMIT 30`,
    [question]
  ),
]);

const fused = reciprocalRankFusion(
  semantic.rows.map((r) => r.id),
  keyword.rows.map((r) => r.id)
);

Combine by rank position rather than by score. A cosine similarity of 0.82 and a ts_rank of 0.19 are not on the same scale, and averaging them produces a number with no meaning. Reciprocal rank fusion only looks at positions, which is why it works without per-corpus tuning.

Reranking, the step that pays for itself

Vector search compares a question vector to chunk vectors that were computed before the question existed. A reranker reads the question and the chunk together and scores that pair directly. It is far more accurate and far too slow to run over a whole corpus, which is exactly why the two-stage design works: retrieve 20 to 50 cheaply, rerank those, keep the best few.

In practice this is the single highest return change available to most retrieval systems, and it is roughly three lines. If recall@20 is good and recall@5 is not, add a reranker before you touch anything else.

Practical notes that cost me time

Embed the question the same way you embed the chunks. Some models expect an asymmetric setup where queries and documents get different prefixes. Get this backwards and quality degrades noticeably with nothing to indicate why.

Store the model name with every vector. Six months later, when you are deciding whether to upgrade, the index needs to be able to tell you what built it. Mixing vectors from two models in one collection produces silent nonsense rather than an error.

Batch your embedding calls. One request per chunk on a 50,000 chunk corpus is slow, expensive in overhead, and will hit a rate limit. Batches of 50 to 100 are usually the practical sweet spot.

Re-embedding is a migration. Changing the model or the chunking strategy invalidates the whole index. Build the new one alongside the old, compare on your test set, then swap. Doing it in place means your search is broken for the duration and you have no way back.

The order I would work in

Write thirty test questions before writing any retrieval code. Build structure-aware chunking with document and heading context prepended. Measure recall@5 and recall@20. Add a reranker. Add keyword search if your domain contains identifiers. Only then start adjusting chunk sizes, because by that point you can actually see whether a change helped.

Nearly every retrieval system I have seen struggle was skipping the measurement step, and every one of them was tuning the prompt instead. Once retrieval is solid, the remaining work is on the request itself, caching the stable prefix and constraining output, which I covered in LLM API integration.
